TP-581T, TP-582T and TP‑582R - Overview

 Two RJ-45 CAT 5 output connectors: one for the line output and the other

for the Ethernet input

The compact MegaTOOLS® enclosures (for the transmitters and the receiver) let

you rack mount up to two units side-by-side in a 1U 19” rack space when using the

optional RK-T2B rack.

In addition, the TP-582T HDMI Switcher/Line Transmitter also features:

 Two HDMI inputs

 Momentary remote contact closure for input switching

 Front panel input select button

 IR remote control input switching (via the Kramer IR remote control

transmitter)

The TP-582R HDMI Line Receiver DA also features:

 One RJ-45 CAT 5 input connector

 Two HDMI outputs

 An S/PDIF digital audio output

 A TOSLINK

optical audio output

The TP-581T HDMI Line Transmitter also features:

 One HDMI input

3.1 About HDBaseT™ Technology

HDBaseT™ is an advanced all-in-one connectivity technology (Supported by the

HDBaseT Alliance). It is particularly suitable in the consumer home environment

as a digital home networking alternative where it enables you to replace numerous

cables and connectors by a single LAN cable used to transmit uncompressed full

high-definition video, audio, 100BaseT Ethernet, power over cable, as well as

various control signals.

The products described in this user manual are HDBaseT certified.
