TP-581T, TP-582T and TP‑582R - Overview

3 Overview

The TP-582T and TP-582R are a high-quality twisted pair transmitter and receiver

for HDMI, 100BaseT Ethernet, bidirectional RS-232 and IR signals.

With the TP-582T you can select one of two HDMI inputs, and convert it with the

100BaseT Ethernet, RS-232 and IR input signals to a twisted pair signal. The

TP-582R converts the twisted pair signal back to 100BaseT Ethernet, RS-232, IR

and two HDMI outputs, and de-embeds the audio to S/PDIF and TOSLINK® audio

outputs. The TP-581T is identical to the TP-582T but has only one HDMI input.

Since the TP-581T has only one input, it does not have the input selection control which the

TP-582T has (that is, contact closure, IR and front panel input selection).

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

The transmitter/receiver pair features:

 A maximum data transfer rate of 6.75Gbps (2.25Gbps per graphic channel)

(1080p@60Hz 36-bit) over a range of up to 130m (430ft) when using

BC−HDKat6a cables

 HDTV compatibility

 HDMI support for Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed

Audio Channels, Dolby TrueHD, DTS-HD, CEC

 3D pass-through

 HDCP compliance

 EDID PassThru, passes EDID/HDCP signals from source to display

 A bidirectional RS-232 interface over which commands and data can flow in

both directions via the RS-232 interface at rates up to 115200, allowing

status requests and control of the destination unit

 Bidirectional infrared interface for remote control of peripheral devices (see

Section 5.3)

 100BaseT Ethernet interface for connection to a network (see Section 5.5)

 LED status indicators for input, output, link and power
