VP-506 - Operating the VP-506
9
Item
Selections
Parameter
Default
INPUT
FORMAT
DVI / PC / YPBPR
DVI
SETUP
CONTRAST
0-255
128
BRIGHTNESS
0-255
128
SATURATION
0-255
128
SHARPNESS
0-255
128
PHASE
0-31
16
OUTPUT
SETUP
H-POSITION
–50 to +50
0
V-POSITION
–29 to +29 (depends on timing
mode)
0
SIZE
100%, 90%, 95%, 105%,
110%, 115%
100%
ADVANCED
TEST_PATTERN
OFF,WHITE,CROSS,CROSS
HATCH,COLOR BAR,
GRAY SCALE,WHITE
WINDOW, RED, GREEN,
BLUE
OFF
NO_INPUT
WHITE,CROSS,CROSS
HATCH,COLOR BAR,
GRAY SCALE,WHITE
WINDOW, RED, GREEN,
BLUE
BLUE
SAVE
0-3
0
RECALL
0-3
0
FACTORY_RESET
OSD SETUP
OSD_HPOSITION
0-100
15
OSD_VPOSITION
0-100
5
OSD_TIMEOUT
0-100
15
OSD_TRANSPARENCY
0-15
15
INFORMATION
SOURCE
DVI or PC or YPbPr
TIMING
Shows input resolution
(e.g.1024X768@60)
OUTPUT
NTSC or PAL
VERSION
Shows firmware version (e.g.
V1.01)
5.4 Using Test Patterns
The Advanced menu lets you select Test Patterns and Save and Recall setups.
The VP-506 stores nine test patterns. From the Advanced menu, you can select a test
pattern (from 1 to 7) to show on screen. Figure 4 shows test pattern number 1.
