4
VP-506 - Overview
3 Overview
The Kramer VP-506 is a high-quality scan converter for down-scaling computer
graphics (VGA up to UXGA) to PAL or NTSC video. It supports VGA up to UXGA,
as well as the HD resolutions: 480p, 576p, 720p and 1080p.
The VP-506 features:
User-friendly front panel buttons for easy control of ProcAmp functions,
flicker-reduction, image optimization, one-touch freezing, overscanning and
underscanning
Memory locations to save and recall up to four setups, including picture
setup, input setup and output setup, zoom and advanced features
Brightness, contrast, saturation and flicker filter.
High-quality composite video
Selectable video standard (PAL or NTSC)
An external 5V DC source
