VP-506 - Operating the VP-506

Figure 4: Test Pattern Number 1

You can also set a test pattern to appear on the screen when there is no input

connected to the VP-506. To do so, enter the Advanced menu, select No Input

and set a test pattern number. This test pattern will appear when there is no input

connected. For example, set No Input to 1 if you want test pattern 1 (as in Figure

4) to appear when there is no input connected to the unit.

5.5 Saving and Recalling

The VP-506 lets you save and recall up to four setups (from 0 to 3).

The Save mode stores all the menu settings in one of the Save setup numbers.

The Save mode saves the Picture setup, the TV Output setup, the VGA Input Setup, the Zoom

setup, and the advanced setup (test patterns)

Saving Through the Advanced Menu

To save setup 1, for example:

1. Adjust the Picture Setup, the VGA Input Setup, the TV Output Setup, the

Zoom and panning, and the No Input number.

2. In the Advanced menu, select Save and set to number 1.

3. Press ENTER.

The setup is saved.

When disconnecting the unit, the setup that was saved last is stored

and reappears when reconnecting the unit.
