VP-506 - Technical Specifications
13
6 Technical Specifications
INPUT:
1 x DVI-I (DVI-D, VGA, YPbPr) on a 24-pin Molex
connector
OUTPUT:
1 composite video 1Vpp/75 on an RCA connector
INPUT RESOLUTIONS:
Up to WUXGA/1080p
CONTROLS:
Front panel and OSD: ProcAmp video controls, freeze,
underscan /overscan, 8 color bars
POWER CONSUMPTION:
5V DC, 540mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx
INCLUDED ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
RK-1 19" rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
