KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
10
7 Technical Specifications
Table 4 lists the technical specifications:
Table 4: Technical Specifications
1
of the F-110
INPUT: 1 VGA / UXGA on a 15-pin HD connector
OUTPUT: 1 CAT 5 LINE OUTPUT on an 8-pin terminal block connector
RESOLUTION: Up to UXGA
MAX. OUTPUT LEVEL: 2Vpp
DIFF. GAIN
2:
6.3% (worst case)
DIFF. PHASE
2
0.3 Deg (worst case)
K-FACTOR
2
: <0.05%
S/N RATIO
2
: 69.5dB , 5MHz
CONTROLS: ON power LED
COUPLING: DC
POWER SOURCE: 12V DC 250mA, feeding receiver
DIMENSIONS: 5cm x 2.4cm x 4.7cm (1.97" x 0.94" 1.85") W, D, H
WEIGHT: 0.14kg (0.31lbs) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
2 For the transmitter/receiver pair
