Kramer F-110 [5/14] Achieving the best performance
![Kramer F-110 [5/14] Achieving the best performance](/views2/1153717/page5/bg5.png)
Overview
3
cables, motors and so on, which are prone to create electrical interference.
However, since the use of UTP cable might cause inconformity to
electromagnetic standards, Kramer does not commit to meeting the standard
with UTP cable.
3.3 Achieving the Best Performance
To ac
hieve the best performance:
• Use only good quality connection cables
1
to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low-quality cables).
• Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer F-110
away from moisture, excessive sunlight and dust
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
