SIERRA VIDEO
27
Software
Upgrades
Introduction
From time to time software upgrades will be available from Sierra Video. Check our web site
(sierravideo.com) for available downloads, or contact the factory.
Operation
Download the software upgrade to a folder on your PC. From the Panel Configuration window,
select “Update Panel Software”.
The following window will be displayed;
Chapter
4
