SIERRA VIDEO
11
Programming
Introduction
The SCP-20 is programmed with the TyLinx Pro software. Please refer to the TyLinx Pro manual
for correct installation on your PC. It is recommended that the router names and configuration be
applied to the router before programming the SCP control panel; see the TyLinx Pro manual for
details.
Follow the instructions in the TyLinx Pro manual to retrieve the router settings and discover the
control panels connected to the router.
If new control panels are added select “ReSync” on the device map screen of TyLinx Pro to
discover the new panels.
General Settings
The “General Settings” window is the first step to programming an SCP panel. The “General”
window allows you to set the output(s) and level(s) you want the panel to control.
From the Device Map window on TyLinx Pro, double click on the control panel icon.
Chapter
3
