![Asus z170-p d3 [57/85] Cpu current capability auto](/img/pdf.png)
Asus z170-p d3 [57/85] Cpu current capability auto
![Asus z170-p d3 [57/85] Cpu current capability auto](/views2/1162357/page57/bg39.png)
CPU Power Duty Control [T.Probe]
DIGI+VRMDutycontroladjuststhecurrentandthermalconditionsofeverycomponent’s
phase.
[T.Probe]SelecttomaintaintheVRMthermalbalance.
[Extreme]SelecttomaintainthecurrentVRMbalance.
CPU Current Capability [Auto]
Allowsyoutocongurethetotalpowerrange,andextendstheoverclockingfrequencyrange
simultaneously.Congurationoptions:[Auto][100%][110%][120%][130%][140%]
Chooseahighervaluewhenoverclocking,orunderahighCPUloadingforextrapower
support.
CPU Graphics Load-Line Calibration [Auto]
Load-lineisdenedbyIntelVRMspecicationandaffectsGTpowervoltage.TheGT
workingvoltagewilldecreaseproportionallytoGTloading.Higherlevelsoftheload-line
calibrationcangetahighervoltageandbetteroverclockingperformance,butincreasesthe
GTandVRMthermalconditions.Selectfromlevel1to8toadjusttheGTpowervoltagefrom
0%to100%.
TheactualperformanceboostmayvarydependingontheGTspecication.Donotremove
thethermalmodule.
CPU Graphics Current Capability [Auto]
ThisitemallowsyoutoadjustthetotalpowerrangeforGToverclocking.Ahighervalue
providesawidertotalpowerrangeandextendstheoverclockingfrequencyrange
simultaneously.Congurationoptions:[Auto][100%][110%][120%][130%][140%]
Chooseahighervaluewhenoverclocking,orunderahighGTloadingforextrapower
support.
CPU Graphics Switching Frequency [Auto]
ThisitemaffectstheGTtransientresponsespeedandthecomponentthermalproduction.
Select[Manual]tocongureahigherfrequencyforaquickertransientresponsespeed.
Congurationoptions:[Auto][Manual]
DONOTremovethethermalmodule.Thethermalconditionsshouldbemonitored.
ThefollowingitemsappearonlywhenyousettheGTSwitchingFrequencyto[Manual].
CPU Graphics Power Duty Control [T.Probe]
DIGI+VRMDutyControladjuststhecurrentandthermalconditionsofeverycomponent’s
phase.
[T.Probe] SelecttomaintaintheVRMthermalbalance.
[Extreme] SelecttomaintainthecurrentVRMbalance.
ASUS Z170-P D3 2-23
