Z170-P D3 specifications summary
(continued on the next page)
ASUS Unique
Features
Gaming Scenario
Audio Features
- Audio that roars on the battleeld
Media Streamer
- Pipe music or movies from your PC to a smart TV, your entertainment goes
wherever you go!
- Media Streamer app for portable smartphone/tablet, supporting iOS 7 &
Android 4.0 systems
ASUS Exclusive Features
- ASUS Disk Unlocker featuring 3TB+ HDD support
- ASUS AI Charger
- ASUS AI Suite 3
EZ DIY
Push Notice
- Monitor your PC status with smart devices in real time
UEFI BIOS EZ Mode
- Featuring friendly graphics user interface
- ASUS O.C. Tuner
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- Anti Surge
Q-Design
- ASUS Q-Slot
ASUS Quiet
Thermal
Solution
Quiet Thermal Design
- ASUS Fan Xpert 2+
- Stylish Fanless Design: PCH Heat-sink & MOS Heatsink solution
ASUS
Exclusive
Overclocking
Features
Precision Tweaker 2
- vCore: Adjustable CPU Core voltage at 0.005V increment
- iGPU: Adjustable CPU Graphics voltage at 0.005V increment
- vCCIO: Adjustable Analog and Digital I/O voltage at 0.005V increment
- vCCSA: Adjustable CPU System Agent voltage at 0.005V increment
- vDRAM Bus: 160-step Memory voltage control
- vPCH: 3-step Chipset voltage control
SFS (Stepless Frequency Selection)
- BCLK/PCIE frequency tuning from 40MHz up to 170MHz at 0.1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
