2.6.7 Onboard Devices Configuration
HD Audio Controller [Enabled]
[Enabled] EnablestheHDAudioDevice.
[Disabled] DisablestheHDAudioDevice.
ThefollowingtwoitemsappearonlywhenyousettheHD Audio Controller itemto
[Enabled].
Front Panel Type [HD Audio]
Allowsyoutosetthefrontpanelaudioconnector(AAFP)modetolegacyAC’97or
high-denitionaudiodependingontheaudiostandardthatthefrontpanelaudio
modulesupports.
[HD] Setsthefrontpanelaudioconnector(AAFP)modetohighdenition
audio.
[AC97] Setsthefrontpanelaudioconnector(AAFP)modetolegacyAC’97
SPDIF Out Type [SPDIF]
[SPDIF] SetstoanSPDIFaudiooutput.
[HDMI] SetstoanHDMIaudiooutput.
Realtek LAN Controller [On]
[On] EnablestheRealtekLANcontroller.
[Off] Disablesthecontroller.
Realtek PXE Option ROM [Off]
Thisitemappearsonlywhenyousetthepreviousitemto[On]andallowsyoutoenableor
disablethePXEOptionRomoftheRealtekLANcontroller.Congurationoptions:[On][Off]
Serial Port Configuration
Thesub-itemsinthismenuallowyoutosettheserialportconguration.
Serial Port [On]
Allowsyoutoenableordisabletheserialport(COM).Congurationoptions:[On][Off]
Change Settings [IO=3F8h; IRQ=4]
ThisitemappearsonlywhenyousettheSerial Portto[On]andallowsyoutoselect
theSerialPortbaseaddress.Congurationoptions:[IO=3F8h;IRQ=4][IO=2F8h;
IRQ=3][IO=3E8h;IRQ=4][IO=2E8h;IRQ=3]
2.6.8 APM Configuration
Deep S4 [Disabled]
WhenthesystementerstheS4stateandthisitemissetto[Enabled],thesystemwillbeput
todeepS4sleepstatetoreducepowerconsumption.ThesystemindeepS4statecanonly
bewokenupviathepowerbutton.Congurationoptions:[Disabled][Enabled]
2-34 Chapter 2: Getting started
