Z170-P D3 specifications summary
Rear Panel I/O
Ports
1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x HDMI port
1 x DVI port
1 x LAN (RJ45) port
4 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
3 Audio jacks support 8 channel*
* Use a chassis with HD audio module in the front panel to support a 8-channel audio
output.
Internal I/O
Connectors
2 x USB 3.0/2.0 connectors support additional 4 USB ports
2 x USB 2.0/1/1 connectors support additional 4 USB ports
1 x M.2 Socket 3 (for M Key, type 2242/2260/2280 devices)
4 x SATA 6.0Gb/s connectors
1 x CPU Fan connector (PWM mode only)
2 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode) and 4-pin(PWM
mode) coolers control
1 x Front panel audio connector (AAFP)
1 x S/PDIF out header
1 x COM connector
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x System Panel connector
1 x Clear CMOS header
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modied
log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
Support DVD
Drivers
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)
OS support
Windows
®
10 64bit
Windows
®
8.1 64bit
Windows
®
7 32bit/64bit*
* Please refer to ASUS website and download “Windows® 7 installation guide” and
“ASUS EZ installer” to install Windows® 7.
Form factor
ATX Form Factor, 12”x 8.6” (30.5cm x 21.8cm)
Specications are subject to change without notice.
