2.8.9 Boot Option Priorities
Theseitemsspecifythebootdeviceprioritysequencefromtheavailabledevices.The
numberofdeviceitemsthatappearsonthescreendependsonthenumberofdevices
installedinthesystem.
• ToaccessWindows
®
OSinSafeMode,press<F8>afterPOST(Windows
®
8not
supported).
• Toselectthebootdeviceduringsystemstartup,press<F8>whenASUSLogo
appears.
2.8.10 Boot Override
Theseitemsdisplaystheavailabledevices.Thenumberofdeviceitemsthatappearson
thescreendependsonthenumberofdevicesinstalledinthesystem.Clickanitemtostart
bootingfromtheselecteddevice.
2.9 Tool menu
TheToolmenuitemsallowyoutocongureoptionsforspecialfunctions.Selectanitemthen
press<Enter>todisplaythesubmenu.
2.9.1 ASUS EZ Flash 3 Utility
AllowsyoutorunASUSEZFlash3.Press[Enter]tolaunchtheASUSEZFlash3screen.
Formoredetails,seesection 2.1.2 ASUS EZ Flash 3.
2.9.2 Setup Animator [Disabled]
EnablesordisablestheSetupanimator.Congurationoptions:[Disabled][Enabled]
ASUS Z170-P D3 2-43
