Asus rog maximus viii impact [144/220] Window

4-6

Chapter 4: Software Support

Chapter 4

• Windows

7 OS disk to ISO le

- Select Windows 7 OS disk to ISO le then click Next.

- Check I agree and then click Next.

- Select the source of the Windows

7 installation disk then click Next.
