Asus rog maximus viii impact [38/220] Expansion slot

1-24

Chapter 1: Product Introduction

Chapter 1

1.2.5 Expansion slot

Unplug the power cord before adding or removing expansion card. Failure to do so may

cause you physical injury and damage motherboard components.

Slot No. SlotDescription

1 PCIe 3.0 x16 slot
