Asus rog maximus viii impact [200/220] Synchronizing backup files

4-62

Chapter 4: Software Support

Chapter 4

Synchronizing backup les

After creating a junction point, RAMDisk automatically creates a backup folder in the le’s

original location. Use RAMDisk to manually synchronize updates with these backup les.

Click Synchronize to

update your les
