2G6
2-3-9
Connector Pin No. Signal I/O Voltage Description
CN1
Connected
to the main
PWB
YC2
Connected
to the High
voltage unit
YC3
Connected
to the
cooling fan
YC4
Connected
to the fuser
thermistor
YC5
Connected
to the AC
inlet
1 Neutral O 120 V AC Power supply for heater lamp
220 - 240 V AC
3 Live O 120 V AC Power supply for heater lamp
220 - 240 V AC
1 +5V O 5 V DC 5 V DC power supply
2 +5V O 5 V DC 5 V DC power supply
3 FAN I 0/12/24 V DC Cooling fan rotation: High/Low/Stop
4 PGND - Ground Ground
5 PGND - Ground Ground
6 +24V2 I 24 V DC 24 V DC power supply
7 THERM O Analog Fuser thermistor temperature detection signal
8 HEATN I 0/24 V DC Heater lamp: On/Off
9 SLEEP I 0/5 V DC Sleep mode control signal: On/Off
10 EXITN O 0/5 V DC Exit sensor: On/Off
11 ZCROSS O 0/5 V DC (pulse) Zero cross signal
12 +24V1 O 24 V DC 24 V DC power supply
13 +24V1 O 24 V DC 24 V DC power supply
14 SGND - Ground Ground
15 SGND - Ground Ground
1 FAN O 0/12/24 V DC Cooling fan rotation: High/Low/Stop
2 +24V1 O 24 V DC 24 V DC power supply for cooling fan
1 THERM I Analog Fuser thermistor temperature detection signal
2 +5V O 5 V DC 5 V DC power supply for fuser thermistor
L Live I 110 V AC AC input
120 V AC
220 - 240 V AC
N Neutral I 110 V AC AC input
120 V AC
220 - 240 V AC
