Kyocera FS-1030D [134/140] 11 paper duplex printing
![Kyocera FS-1030D [134/140] 11 paper duplex printing](/views2/1163790/page134/bg86.png)
2G6
2-4-2
Timing chart No. 2 Paper cassette feeding, A4/8
1
/2"
××
××
× 11" paper, duplex printing
0 (ms) 10515
0 (ms) 10515
100
1286
800 1377
1477
200
3742 8353 10703
930 5278 8438
3100 5317
1671 11039
1477 84383973 10934
800
1895 4128
111944628
11099
10029 12279
13840
13840
13840
13840
12640
8438
8884
5537 5737
8037 8237
4078
4078
6331 8540
7438
8632
DUDR1
(Switchback solenoid)
DUDR2
(Switchback solenoid)
+570 V
0 V
-1800 V
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR/RTHVDR
(Transfer charger)
PFMDRN
(Cassette feed motor)
RESDRN
(Registration solenoid)
OUTPEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
RESIT
(Registration sensor)
EXITN
(Exit sensor)
Drum speed: 132 mm/s
Paper feeding speed: 222 mm/s
Printing speed: 10.30 ppm
