Kyocera FS-1030D [61/140] 6 the registration solenoid does not operate
![Kyocera FS-1030D [61/140] 6 the registration solenoid does not operate](/views2/1163790/page61/bg3d.png)
2G6
1-5-19
Problem Causes Check procedures/corrective measures
(6)
The registration so-
lenoid does not op-
erate.
(7)
The switchback so-
lenoid does not op-
erate.
(8)
The eraser lamp
does not turn on.
(9)
The heater lamp
does not turn on.
(10)
The heater lamp
does not turn off.
(11)
Main charging is not
performed.
(12)
Transfer charging is
not performed.
Broken registration sole-
noid coil.
Poor contact in the regis-
tration solenoid connector
terminals.
Defective engine PWB
(K0010).
Broken switchback sole-
noid coil.
Poor contact in the
switchback solenoid con-
nector terminals.
Defective engine PWB
(K0010).
Poor contact in the eraser
lamp connector terminals.
Defective eraser lamp.
Defective engine PWB
(K0010).
Broken wire in heater
lamp.
Thermal cutout triggered.
Defective engine PWB
(K0010).
Dirty sensor part of the
fuser thermistor.
Broken main charger wire.
Leaking main charger
housing.
Poor contact in the high
voltage board connector
terminals.
Defective engine PWB
(K0010).
Defective high voltage
unit.
Poor contact in the high
voltage unit connector ter-
minals.
Defective engine PWB
(K0010).
Defective high voltage
unit.
Check for continuity across the coil. If none, replace the regis-
tration solenoid.
Reinsert the connector. Also check for continuity within the con-
nector cable. If none, remedy or replace the cable.
Replace the engine PWB (K0010). See page 1-6-9.
Check for continuity across the coil. If none, replace the
switchback solenoid.
Reinsert the connector. Also check for continuity within the con-
nector cable. If none, remedy or replace the cable.
Replace the engine PWB (K0010). See page 1-6-9.
Reinsert the connector. Also check for continuity within the con-
nector cable. If none, remedy or replace the cable.
Check for continuity. If none, replace the eraser lamp. See page
1-6-30.
If the eraser lamp turns on when YC14-2 on the engine PWB
(K0010) is held low, replace the engine PWB (K0010). See
page 1-6-9.
Check for continuity across heater lamp. If none, replace the
heater lamp. See page 1-6-22.
Check for continuity across thermal cutout. If none, remove the
cause and replace the thermal cutout. See page 1-6-26.
Replace the engine PWB (K0010). See page 1-6-9.
Check visually and clean the fuser thermistor sensor parts.
See page 1-5-13.
See page 1-5-13.
