Ariete 4160 [11/55] Save these instructions for future reference

• Fill up the tank with water before starting up the appliance. Be sure to unplug the appliance before pouring water into

the tank.

• Turn on the appliance only when it is in working position.

• Never leave the appliance unattended when it is connected to the power supply.

• When you have to leave for even a short period of time, turn off the appliance and always unplug the electric power cord.

• Store indoors in a cool, dry area.

• 



A - Steam dispensing button

H - Water tank

I - Filter

J - Fixed cord storage hook

K - Steam head

L - Washable cloth

M - Power supply cable

N - Accessory for carpet cleaning

O - Washable cloth velcro couplings

P - Steam discharge nozzle



Totally unwind the power cord. To make the operation easier, turn the hook (C) downwards.

Remove the tank. Lift the tank release lever upwards as shown by the arrow (Fig. 6). At the same time tilt and remove the

tank. Turn the tank upside-down. Remove the cap (Fig. 7). Fill the tank up to the MAX level directly beneath the tap with cool

tap water (Fig. 8). Screw the cap back on, but not with excessive force.



NEVER ll the tank beyond the MAX level. If the tap water is particularly hard (higher than 20°f), use a mixture of

50% tap water and 50% demineralised water.

Put the tank back in, paying attention to match the tank valve with the pin in the appliance seat (Fig. 9). Press the tank all

the way down until it is completely inserted and check that it is correctly installed. Place the cloth under the steam head

(Fig. 10). Set the cloth above the velcro couplings.

If the appliance is left standing on the oor while it is in operation, you may notice a whitish ring. Do not be alarmed

because this can be removed with a decalcication agent or with some drops of vinegar.

Insert the plug into the socket, which must be earthed. The indicator lamp (E) will turn on, indicating that the appliance is on

11


