150Mbps/300Mbps Wireless-N AP / Repeater / Router client User Manual
26
Request timed out.
Request timed out.
Request timed out.
Request timed out.
Ping statistics for 192.168.1.1:
Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),
Verify your computer's network settings are correct and check the cable connection between the
router and the computer.
In order to make the whole network operate successfully, it is necessary to configure the
150Mbps/300Mbps Wireless-N AP/ Repeater / Router client through your computer has a
WEB browser installed. Please follow up the steps listed below.
3.3. Login
Ø Open a web browser (Safari, Internet Explorer, etc.) on the computer you have just
connected to the router, type http://192.168.1.1 in the address bar, and press enter. You will
login the UI automatically
Figure 3-18
Ø After you have logged in, the router's user interface will be displayed. The left menu shows
