150Mbps/300Mbps Wireless-N AP / Repeater / Router client User Manual

you set is not in accord with the value ISP provide, it may causes some problems, such as

fail to send Email, or fail to browse website. So if that happen, you can contact your ISP for

more information and correct your router’s MTU value.

Ø Primary DNS: The DNS server translates domain or website names into IP address, input

the most common DNS server address you used or provided by your ISP.

Ø Secondary DNS: Input IP address of a backup DNS server or you can leave this field

blank.

4.4.2. LAN

The IP address of LAN port is used for access router itself by computers that connect to the

router directly; here you can set IP address you need. The IP address format is like

***.***.***.***, and default IP address is 192.168.1.1, the default subnet mask is

255.255.255.0.

Figure 4-1

4.4.3. MAC Clone

The WAN port of router has a unique MAC address assigned by manufacturer; it called as

“Default MAC”. The “Clone MAC” is used for some special situations; For example, ISP only

allows certain MAC address to access the Internet, thus you can modify your WAN port’s MAC

address in accord with the requirement of ISP, avoiding ISP’s detection.

Figure 4-21

4.4.4. Port Settings

Here you can set the router's WAN and LAN interfaces work at 100M duplex,100M

half-duplex,10M duplex and 10M half-duplex communication mode.
