Hardware Installation
- 10 -
1-2 ProductSpecications
CPU Built in with an Intel
®
Single-core Atom
™
D425 processor (1.8 GHz)
* Do not disassemble the onboard CPU/chipset and the heatsinks/fan by yourself to
avoid damage to these components.
512K L2 cache
Chipset Intel
®
NM10
Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 4 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
Support for DDR3 800 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek ALC887 codec
HighDenitionAudio
2/4/5.1/7.1-channel
* To enable 7.1-channel audio, you have to use an HD front panel audio module and
enable the multi-channel audio feature through the audio driver.
LAN Realtek GbE LAN Chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI slot
Storage Interface Chipset:
- 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices
USB Chipset:
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal
Connectors
1 x 20-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x chassis intrusion header
1 x power LED header
