Gigabyte GA-D425TU(D) [8/72] Ga d425tu motherboard block diagram

- 8 -

GA-D425TU Motherboard Block Diagram

Line-Out (Front Speaker Out)

MIC (Center/Subwoofer Speaker Out)

Line-In (Rear Speaker Out)

CODEC

PS/2 KB/Mouse

Intel

Atom

™

CPU

DMI

Interface

1 PCI

PCI Bus

PCI CLK

(33 MHz)

CPU CLK+/- (200 MHz)

2 SATA 3Gb/s

Dual BIOS

DDR3 800 MHz

Memory

LPC Bus

LPT

Intel

NM10

8 USB 2.0/1.1

PCI Express Bus

LAN

RJ45

PCIe CLK

(100 MHz)

D-Sub

COM

iTE

Super

I/O

Realtek

GbE LAN

Fordetailedproductinformation/limitation(s),referto"1-2ProductSpecications."
