BIOS Setup
- 32 -
2-6 Integrated Peripherals
SATA AHCI Mode (NM10 Chipset, SATA2_0/1 Connectors)
AllowsyoutodecidewhethertoconguretheSATAcontrollersintegratedintheNM10ChipsettoAHCI
mode.
IDE CongurestheSATAcontrollerstoIDEmode.(Default)
AHCI CongurestheSATAcontrollerstoAHCImode.AdvancedHostControllerInterface(AHCI)is
aninterfacespecicationthatallowsthestoragedrivertoenableadvancedSerialATAfeatures
such as Native Command Queuing and hot plug.
Azalia Codec
Enables or disables the onboard audio function. (Default: Auto)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item to
Disabled.
Onboard H/W LAN
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled.
Green LAN
When the onboard LAN function and Green LAN are enabled, the system will dynamically detect if a
LAN cable is connected or not. If not, the corresponding LAN controller will be disabled automatically.
(Default: Disabled)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
SATA AHCI Mode [IDE]
Azalia Codec [Auto]
Onboard H/W LAN [Enabled]
Green LAN [Disabled]
SMART LAN [Press Enter]
Onboard LAN Boot ROM [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
USB 1.0 Controllers [Enabled]
USB 2.0 Controllers [Enabled]
USB Keyboard Function [Disabled]
USB Mouse Function [Disabled]
USB Storage Function [Enabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
