BIOS Setup
- 30 -
2-5 Advanced BIOS Features
Hard Disk Boot Priority
Speciesthesequenceofloadingtheoperatingsystemfromtheinstalledharddrives.Usetheupor
down arrow key to select a hard drive, then press the plus key <+> (or <PageUp>) or the minus key <-> (or
<PageDown>)tomoveitupordownonthelist.Press<Esc>toexitthismenuwhennished.
Quick Boot
Enables or disables the quick boot function to speed up the system boot-up process to shorten the
waitingtimeforenteringtheoperatingsystemandtodelivergreaterefciencyfordailyuse.(Default:
Disabled)
First/Second/Third Boot Device
Speciesthebootorderfromtheavailabledevices. Usetheupordownarrowkeytoselectadevice
and press <Enter> to accept. Options are: LS120, Hard Disk, CDROM, ZIP, USB-FDD, USB-ZIP, USB-
CDROM, USB-HDD, Legacy LAN, Disabled.
Password Check
Specieswhether a passwordisrequiredevery time thesystemboots,or only when youenterBIOS
Setup.Afterconguringthisitem,setthepassword(s)undertheSet Supervisor/User Password item in
the BIOS Main Menu.
Setup A password is only required for entering the BIOS Setup program. (Default)
System A password is required for booting the system and for entering the BIOS Setup
program.
HDD S.M.A.R.T. Capability
Enables or disables the S.M.A.R.T. (Self Monitoring and Reporting Technology) capability of your hard
drive. This feature allows your system to report read/write errors of the hard drive and to issue warnings
when a third party hardware monitor utility is installed. (Default: Enabled)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced BIOS Features
Hard Disk Boot Priority [Press Enter]
Quick Boot [Disabled]
First Boot Device [Hard Disk]
Second Boot Device [CDROM]
Third Boot Device [USB-FDD]
Password Check [Setup]
HDD S.M.A.R.T. Capability [Enabled]
CPU Multi-Threading
[Enabled]
Limit CPUID Max. to 3
[Disabled]
Delay For HDD (Secs) [0]
Backup BIOS Image to HDD [Disabled]
Init Display First [PCI]
On-Chip Frame Buffer Size [8MB+1 for GTT]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
