Gigabyte GA-D425TU(D) [15/72] 5 internal connectors

- 15 -

Hardware Installation

1-5 Internal Connectors

Read the following guidelines before connecting external devices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the

power cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

12 46

1) ATX_12V

2) ATX

3) CPU_FAN

4) SYS_FAN

5) SATA2 0/1

6) PWR_LED

7) BAT

8) F_PANEL

9) F_AUDIO

10) F_USB1/F_USB2

11) COMB

12) CI
