Gigabyte GA-D425TU(D) [29/72] Halt on

- 29 -

BIOS Setup

Halt On

Allows you to determine whether the system will stop for an error during the POST.

All Errors Whenever the BIOS detects a non-fatal error the system boot will stop.

No Errors The system boot will not stop for any error.

All, But Keyboard The system boot will not stop for a keyboard error but stop for all other errors.

(Default)

Memory

 Theseeldsareread-onlyandaredeterminedbytheBIOSPOST.

Base Memory Also called conventional memory. Typically, 640 KB will be reserved for the MS-

DOS operating system.

Extended Memory The amount of extended memory.

Total Memory The total amount of memory installed on the system.
