Operations 19

Remove the security bezel (optional)

To access the front panel components, unlock and then remove the security bezel.

Remove the access panel

WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

CAUTION: Do not operate the server for long periods with the access panel open or removed.

Operating the server in this manner results in improper airflow and improper cooling that can

lead to thermal damage.

To remove the component:

1. Power down the server (on page 16).

2. Remove all power:

a. Disconnect each power cord from the power source.

b. Disconnect each power cord from the server.

3. Do one of the following:

o Extend the server from the rack (on page 17).

o Remove the server from the rack (on page 16).

4. Open the locking latch, slide the access panel to the rear of the chassis, and then remove the access

panel.

If the locking latch is engaged, then use a T-15 Torx screwdriver to unlock the latch.

Install the access panel

1. Place the access panel on top of the server with the locking latch open. Allow the panel to extend past

the rear of the server by approximately 1.25 cm (0.5 inch).
