HP dl160gen8 [72/109] Fbwc capacitor pack cabling

Cabling 72

FBWC capacitor pack cabling

Cable number Description

FBWC capacitor pack cable

Front panel cabling

Cable number Description

2x10 Front panel IO cable

2x12 Front panel IO cable
