Chapter 1 Introduction
ZyWALL USG 20-2000 User’s Guide
13
Dashboard
The dashboard displays general device information, system status, system resource usage, licensed
service status, and interface status in widgets that you can re-arrange to suit your needs. See the
Web Help for details on the dashboard.
Monitor Menu
The monitor menu screens display status and statistics information.
Table 4 Monitor Menu Screens Summary
FOLDER OR LINK TAB FUNCTION
System Status
Port Statistics Displays packet statistics for each physical port.
Interface
Status
Displays general interface information and packet statistics.
Traffic
Statistics
Collect and display traffic statistics.
Session
Monitor
Displays the status of all current sessions.
DDNS Status Displays the status of the ZyWALL’s DDNS domain names.
IP/MAC Binding Lists the devices that have received an IP address from ZyWALL interfaces using
IP/MAC binding.
Login Users Lists the users currently logged into the ZyWALL.
WLAN Status Displays the connection status of the ZyWALL’s wireless clients.
Cellular Status Displays details about the ZyWALL’s 3G connection status.
USB Storage Displays details about USB device connected to the ZyWALL.
AppPatrol
Statistics
Displays bandwidth and protocol statistics.
VPN Monitor
IPSec Displays and manages the active IPSec SAs.
SSL Lists users currently logged into the VPN SSL client portal. You can also log out
individual users and delete related session information.
L2TP over
IPSec
Displays details about current L2TP sessions.
Anti-X Statistics
Anti-Virus Collect and display statistics on the viruses that the ZyWALL has detected.
IDP Collect and display statistics on the intrusions that the ZyWALL has detected.
Content Filter Report Collect and display content filter statistics
Cache Manage the ZyWALL’s URL cache.
Anti-Spam Report Collect and display spam statistics.
Status Displays how many mail sessions the ZyWALL is currently checking and DNSBL
(Domain Name Service-based spam Black List) statistics.
Log Lists log entries.
