ZyWALL USG 20-2000 User’s Guide 69

CHAPTER 4

Create Secure Connections Across the

Internet

These sections cover using VPN to create secure connections across the Internet.

• IPSec VPN on page 69

• VPN Concentrator Example on page 71

• Hub-and-spoke IPSec VPN Without VPN Concentrator on page 73

• ZyWALL IPSec VPN Client Configuration Provisioning on page 75

• SSL VPN on page 77

• L2TP VPN with Android, iOS, and Windows on page 79

• One-Time Password Version 2 (OTPv2) on page 92

4.1 IPSec VPN

Besides using the VPN quick setup wizard to configure settings for an IPSec VPN tunnel, you can

use the Configuration > VPN > IPSec VPN screens to configure and activate or deactivate VPN

gateway and IPSec VPN connection policies. You can also connect or disconnect IPSec VPN

connections.

•Use the VPN Gateway screens to manage the ZyWALL’s VPN gateways. A VPN gateway specifies

the IPSec routers at either end of a VPN tunnel and the IKE SA settings (phase 1 settings). You

can also activate or deactivate each VPN gateway.

•Use the VPN Connection screens to specify which IPSec VPN gateway an IPSec VPN connection

policy uses, which devices behind the IPSec routers can use the VPN tunnel, and the IPSec SA

settings (phase 2 settings). You can also activate or deactivate and connect or disconnect each

VPN connection (each IPSec SA).

4.1.1 Test the VPN Connection

After you configure the VPN gateway and VPN connection settings, set up the VPN settings on the

peer IPSec router and try to establish the VPN tunnel. To trigger the VPN, either try to connect to a

device on the peer IPSec router’s LAN or click Configuration > VPN > IPSec VPN > VPN

Connection and use the VPN connection screen’s Connect icon.

4.1.2 Configure Security Policies for the VPN Tunnel

You configure security policies based on zones. The new VPN connection was assigned to the

IPSec_VPN zone. By default, there are no security restrictions on the IPSec_VPN zone, so, next,

you should set up security policies that apply to the IPSec_VPN zone.
