Chapter 27 IGMP Snooping Commands
Ethernet Switch CLI Reference Guide
122
This example limits the number of multicast groups on port 1 to 5.
This example shows the current multicast groups on the Switch.
The following table describes the labels in this screen.
This example shows the current multicast VLAN on the Switch.
sysname# configure
sysname(config)# igmp-snooping
sysname(config)# interface port-channel 1
sysname(config-interface)# igmp-snooping group-limited
sysname(config-interface)# igmp-snooping group-limited number 5
sysname(config-interface)# exit
sysname(config)# exit
sysname# show interfaces config 1 igmp-snooping group-limited
Port Enable Max Multicast Group
1 YES 5
sysname# show multicast
Multicast Status
Index VID Port Multicast Group Timeout
----- ---- ---- ---------------- -------
Table 71 show multicast
LABEL DESCRIPTION
Index This field displays an entry number for the VLAN.
VID This field displays the multicast VLAN ID.
Port This field displays the port number that belongs to the multicast group.
Multicast Group This field displays the IP multicast group addresses.
Timeout This field displays how long the port will belong to the multicast group.
sysname# show multicast vlan
Multicast Vlan Status
Index VID Type
----- ---- ----------
1 3 MVR
