Ethernet Switch CLI Reference Guide
247
CHAPTER 62
RIP Commands
This chapter explains how to use commands to configure the Routing Information Protocol
(RIP) on the Switch.
62.1 RIP Overview
RIP is a protocol used for exchanging routing information between routers on a network.
Information is exchanged by routers periodically advertising a routing table. The Switch can
be configured to receive and incorporate routing table information sent from other routers, to
only send routing information to other routers, both send and receive routing information, or
to neither send nor receive routing information to or from other routers on the network.
62.2 Command Summary
The following section lists the commands for this feature.
Table 136 rip Command Summary
COMMAND DESCRIPTION M P
show router rip Displays global RIP settings. E 3
show ip protocols Displays the routing protocol the Switch is
using and its administrative distance value.
E3
router rip Enables and enters the RIP configuration
mode on the Switch.
C13
