Chapter 35 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
172
35.3 Command Examples
This example enables LLDP on the Switch, sets port 2 to send and receive LLDP packets and
allows the Switch to send optional basic management TLVs (such as management-address,
port-description and system-description TLVs) on port 2. This example also shows the LLDP
settings on port 2 and global LLDP settings on the Switch.
show lldp statistic interface port-
channel <port-list>
Displays LLDP statistics of the specified port(s). E 13
clear lldp statistic Resets the LLDP statistics counters to zero. E 13
clear lldp remote_info Deletes all device information from the neighboring
devices.
E13
clear lldp remote_info interface
port-channel <port-list>
Deletes remote device information on the specified
port(s).
E13
Table 96 lldp Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# configure
sysname(config)# lldp
sysname(config)# interface port-channel 2
sysname(config-interface)# lldp admin-status tx-rx
sysname(config-interface)# lldp basic-tlv management-address
sysname(config-interface)# lldp basic-tlv port-description
sysname(config-interface)# lldp basic-tlv system-description
sysname(config-interface)# exit
sysname(config)# exit
sysname# show lldp config interface port-channel 2
LLDP Port Configuration:
Port AdminStatus Notification BasicTLV Dot1TLV Dot3TLV
2 tx-rx Disable P-D-M -- ----
Basic TLV Flags: (P)Port Description, (N)System Name, (D)System
Description
(C)System Capabilities, (M)Management Address
802.1 TLV Flags: (P)Port & Protocol VLAN ID, (V)Port VLAN ID
802.3 TLV Flags: (L)Link Aggregation, (M)MAC/PHY Configuration/Status
(F)Maximun Frame Size, (P)Power Via MDI
sysname# show lldp config
LLDP Global Configuration:
Active: Yes
Transmit Interval: 30 seconds
Transmit Hold: 4
Transmit Delay: 2 seconds
Reinitialize Delay: 2 seconds
sysname#
