Chapter 44 Mirror Commands
Ethernet Switch CLI Reference Guide
191
This example displays the mirror settings of the Switch after you configured in the example
above.
sysname# show mirror
Mirroring: enable
Monitor port: 3
Mirrored port: 1,4-6
Ingress:
Egress: 1,4-6
Both:
