Chapter 78 VLAN Commands
Ethernet Switch CLI Reference Guide
299
This example displays concurrent incoming packet statistics for VLAN 1.
The following table describes the labels in this screen.
MGS-3712# show vlan 1 counters
-------- Press ESC to finish -------
System up time: 0:59:02
Vlan Info Vlan Id. :1
Packet KBs/s :0.0
Packets :2
Multicast :0
Broadcast :2
Tagged :0
Distribution 64 :2
65 to 127 :0
128 to 255 :0
256 to 511 :0
512 to 1023 :0
1024 to 1518 :0
Giant :0
-------- Press ESC to finish -------
System up time: 0:59:12
Vlan Info Vlan Id. :1
Packet KBs/s :0.384
Packets :10
Multicast :0
Broadcast :10
Tagged :0
Distribution 64 :10
65 to 127 :0
128 to 255 :0
256 to 511 :0
512 to 1023 :0
1024 to 1518 :0
Giant :0
Table 172 show vlan counters
LABEL DESCRIPTION
System up time This field shows the total amount of time the connection has been up.
VLAN Info This field displays the VLAN ID you are viewing.
Packet
KBs/s This field shows the number kilobytes per second flowing through this
VLAN.
Packets This field shows the number of good packets (unicast, multicast and
broadcast) flowing through this VLAN.
Multicast This field shows the number of good multicast packets flowing through this
VLAN..
Broadcast This field shows the number of good broadcast packets flowing through this
VLAN..
Tagged This field shows the number of VLAN-tagged packets flowing through this
VLAN.
Distribution
