Chapter 85 Additional Commands
Ethernet Switch CLI Reference Guide
319
85.2 Command Examples
This example checks the cable pairs on port 7.
traceroute <ip|host-name> [vlan
<vlan-id>] [ttl <1-255>] [wait
<1-60>] [queries <1-10>]
Determines the path a packet takes to the specified Ethernet
device.
vlan <vlan-id>: Specifies the VLAN ID to which the
Ethernet device belongs.
ttl <1-255>: Specifies the Time To Live (TTL) period.
wait <1-60>: Specifies the time period to wait.
queries <1-10>: Specifies how many times the Switch
performs the traceroute function.
E0
traceroute help Provides more information about the specified command. E 0
write memory [<index>] Saves current configuration in volatile memory to the
configuration file the Switch is currently using or the specified
configuration file.
E13
Table 181 Command Summary: Additional Configure Mode
COMMAND DESCRIPTION M P
bcp-transparency Enables Bridge Control Protocol (BCP) transparency on the
Switch.
C13
default-management <in-
band|out-of-band>
Sets which traffic flow (in-band or out-of-band) the Switch
sends packets originating from itself (such as SNMP traps) or
packets with unknown source.
C13
hostname <name> Sets the Switch’s name for identification purposes.
name: 1-64 printable characters; spaces are allowed if you
put the string in double quotation marks (“).
C13
install help Displays command help information. C 13
install slot <slot-list> type
<card-type>
Changes what type of card is in the slot without restarting the
system.
C13
no install slot <slot> Uninstalls the card in the slot. C 13
mode zynos Changes the CLI mode to the ZyNOS format. C 13
no shutdown slot <slot-list> Turns on the power to the slot. C 13
shutdown slot <slot-list> Turns off the power to the slot. C 13
transceiver-ddm timer <1 -
4294967>
Sets the duration of the digital diagnostic monitoring (DDM)
timer.
This defines how often (in miliseconds) the Switch sends the
digital diagnostic monitoring (DDM) information via the
installed transceiver(s).
C13
Table 180 Command Summary: Additional Enable Mode (continued)
COMMAND DESCRIPTION M P
sysname# cable-diagnostics 7
port 7
cable diagnostics result
pairA: Ok
pairB: Ok
