Ethernet Switch CLI Reference Guide
189
CHAPTER 44
Mirror Commands
Use these commands to copy a traffic flow for one or more ports to a monitor port (the port
you copy the traffic to) so that you can examine the traffic on the monitor port without
interference.
Use the running configuration commands to look at the current mirror settings.
See Chapter 64 on page 255.
mirror-filter commands are not supported on all Switch models.
44.1 Command Summary
The following section lists the commands for this feature.
Table 108 mirror Command Summary
COMMAND DESCRIPTION M P
mirror-port Enables port mirroring on the Switch. C 13
mirror-port <port-num> Specifies the monitor port (the port to which traffic flow is
copied) for port mirroring.
C13
no mirror-port Disables port mirroring on the Switch. C 13
no mirror-port <port-num> Removes the specified monitor port.
port-num: in a modular switch, enter the port number
preceded by a slot number and backslash (/). For example, 3/
11 indicates port 11 on the card in the third slot.
C13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s).
port-list: in a modular switch, enter the port number
preceded by a slot number and backslash (/). For example, 3/
11 indicates port 11 on the card in the third slot. Use a comma
(,) to separate individual ports or a desh (-) to indicates a
range of ports. For example, “3/11,4/5” or “3/7-3/9”.
C13
mirror Enables port mirroring in the interface. C 13
