Chapter 46 MSTP Commands
Ethernet Switch CLI Reference Guide
199
This example adds the Switch to the MST region MSTRegionNorth. MSTRegionNorth is on
revision number 1. In MSTRegionNorth, VLAN 2 is in MST instance 1, and VLAN 3 is in
MST instance 2.
sysname# configure
sysname(config)# mstp
sysname(config)# mstp configuration-name MSTRegionNorth
sysname(config)# mstp revision 1
sysname(config)# mstp instance 1 vlan 2
sysname(config)# mstp instance 2 vlan 3
sysname(config)# exit
