3.5-inch
SATA
Simple
Swap
4 Integrated
8-port
6 Gbps SATA
(no RAID
support)
Factory installed:
1x System x3550 M5 4x 3.5" SS HDD Kit, Non-Raid (FC A5A5)
1x M1215; or
1x M5210; or
1x N2215
Factory installed:
1x System x3550 M5 4x 3.5" SS HDD Kit, HW RAID (FC A5A8)
Drive bay
type
Drive
bay
qty
Storage controller Drive kits required
Controllers for internal storage
The following table lists the RAID controllers and the additional options used for the internal storage of the
x3550 M5 server. The controllers are installed into a dedicated PCIe slot.
Table 9. RAID controllers and HBAs for internal storage
Part
number
Feature
code
Description Maximum
supported
Standard models
where used
12 Gb SAS/SATA controllers
46C9110 A3YZ ServeRAID M5210 SAS/SATA Controller 1 62x, D2x, F2x,
G2x, H2x, J2x,
L2x, M2x, N2x,
P2x, Q2x
46C9114 A45W ServeRAID M1215 SAS/SATA Controller 1 A2x, B2x, C2x,
C4x
47C8675 A3YY N2215 SAS/SATA HBA 1 -
Hardware upgrades for the M5210 (per one controller)
47C8656 A3Z0 ServeRAID M5200 Series 1GB Cache/RAID 5 Upgrade 1 -
47C8660 A3Z1 ServeRAID M5200 Series 1GB Flash/RAID 5 Upgrade 1 D2x, F2x, G2x,
H2x
47C8664 A3Z2 ServeRAID M5200 Series 2GB Flash/RAID 5 Upgrade 1 62x, J2x, N2x,
P2x, Q2x
47C8668 A3Z3 ServeRAID M5200 Series 4GB Flash/RAID 5 Upgrade 1 -
Features on Demand upgrades for the M5210 (per one server)**
47C8708 A3Z6 ServeRAID M5200 Series Zero Cache/RAID 5 Upgrade 1 -
47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade 1* -
47C8710 A3Z7 ServeRAID M5200 Series Performance Accelerator 1* -
47C8712 A3Z8 ServeRAID M5200 Series SSD Caching Enabler 1* -
Features on Demand upgrades for the M1215 (per one server)**
00AE930 A5H5 ServeRAID M1200 Zero Cache/RAID 5 Upgrade 1 -
* Requires cache memory upgrade (47C8656, 47C8660, 47C8664, or 47C8668).
** ServeRAID Feature on Demand upgrades are system-wide. One FoD upgrade part number will enable the feature on all
ServeRAID M5200 Series adapters (M5210, M5210e, M5225) installed in the server.
Lenovo System x3550 M5 16
