The following table lists drive types and internal bays supported by the drive controllers.
Table 11. Controllers, drive types, and internal drive bays
Drive
controller
Drive type Drive bays
Up to 12x 2.5-inch
hot-swap
Up to 8x 2.5-inch
Simple Swap
4x 3.5-inch
hot-swap
4x 3.5-inch
Simple Swap
Integrated
SATA
SAS/NL SAS HDD No No No No
NL SATA HDD No Yes No Yes
SAS SED No No No No
SAS SSD No No No No
SATA SSD No No No No
M1215
M5210
SAS/NL SAS HDD Yes No Yes No
NL SATA HDD Yes Yes Yes Yes
SAS SED Optional* No No No
SAS SSD Yes No No No
SATA SSD Yes No Yes No
N2215 SAS/NL SAS HDD Yes No Yes No
NL SATA HDD Yes Yes Yes Yes
SAS SED No No No No
SAS SSD Yes No No No
SATA SSD Yes No Yes No
* SEDs are supported with RAID 5 FoD upgrades or cache upgrades.
Drives for internal storage
The following table lists hard drive options for internal disk storage of the x3550 M5 server.
Table 12. Internal drive options (Part 1: 2.5-inch hot-swap drives)
Part
number
Feature
code
Description Maximum
supported
2.5-inch hot-swap HDDs - 12 Gbps SAS
00WG685 AT89 300GB 10K 12Gbps SAS 2.5" G3HS HDD 12
00WG660 AT84 300GB 15K 12Gbps SAS 2.5" G3HS HDD 12
00NA221 ASBB 300GB 15K 12Gbps SAS 2.5" G3HS 512e HDD 12
00WG690 AT8A 600GB 10K 12Gbps SAS 2.5" G3HS HDD 12
00NA241 ASBF 600GB 10K 12Gbps SAS 2.5" G3HS 512e HDD 12
00WG665 AT85 600GB 15K 12Gbps SAS 2.5" G3HS HDD 12
00NA231 ASBD 600GB 15K 12Gbps SAS 2.5" G3HS 512e HDD 12
00WG695 AT8B 900GB 10K 12Gbps SAS 2.5" G3HS HDD 12
00NA251 ASBH 900GB 10K 12Gbps SAS 2.5" G3HS 512e HDD 12
00WG700 AT8C 1.2TB 10K 12Gbps SAS 2.5" G3HS HDD 12
00NA261 ASBK 1.2TB 10K 12Gbps SAS 2.5" G3HS 512e HDD 12
00NA271 ASBM 1.8TB 10K 12Gbps SAS 2.5" G3HS 512e HDD 12
Lenovo System x3550 M5 18
