![Lenovo x3550 m5, 5463e1g [20/47] Table 12 internal drive options part 2 2 inch simple swap drives](/img/pdf.png)
Lenovo x3550 m5, 5463e1g [20/47] Table 12 internal drive options part 2 2 inch simple swap drives
![Lenovo x3550 m5, 5463e1g [20/47] Table 12 internal drive options part 2 2 inch simple swap drives](/views2/1173096/page20/bg14.png)
2.5-inch hot-swap SSDs - Enterprise Entry 6 Gbps SATA
00YC385 AT8R 120GB Enterprise Entry SATA G3HS 2.5" SSD 12
00YC390 AT8S 240GB Enterprise Entry SATA G3HS 2.5" SSD 12
00YC395 AT8T 480GB Enterprise Entry SATA G3HS 2.5" SSD 12
00YC400 AT8U 960GB Enterprise Entry SATA G3HS 2.5" SSD 12
00WG620 AT93 S3510 120GB Enterprise Entry SATA G3HS 2.5" SSD 12
00WG625 AT94 S3510 240GB Enterprise Entry SATA G3HS 2.5" SSD 12
00WG630 AT95 S3510 480GB Enterprise Entry SATA G3HS 2.5" SSD 12
00WG635 AT96 S3510 800GB Enterprise Entry SATA G3HS 2.5" SSD 12
2.5-inch hot-swap SSDs - Enterprise Value 6 Gbps SATA
00AJ395 A577 120GB SATA 2.5" MLC G3HS Enterprise Value SSD 12
00AJ400 A578 240GB SATA 2.5" MLC G3HS Enterprise Value SSD 12
00AJ405 A579 480GB SATA 2.5" MLC G3HS Enterprise Value SSD 12
00AJ410 A57A 800GB SATA 2.5" MLC G3HS Enterprise Value SSD 12
00AJ171 A4U6 S3500 120GB Enterprise Value SATA G3HS 2.5" SSD 12
00AJ176 A4U7 S3500 240GB Enterprise Value SATA G3HS 2.5" SSD 12
00AJ181 A4U8 S3500 480GB Enterprise Value SATA G3HS 2.5" SSD 12
00AJ186 A4U9 S3500 800GB Enterprise Value SATA G3HS 2.5" SSD 12
2.5-inch hot-swap SSDs - Enterprise Capacity 6 Gbps SAS
00NA671 ASW6 3.84TB 6Gb SAS Enterprise Capacity G3HS MLC SSD 10
Part
number
Feature
code
Description Maximum
supported
Table 12. Internal drive options (Part 2: 2.5-inch simple-swap drives)
Part
number
Feature
code
Description Maximum
supported
2.5-inch simple-swap HDDs - 6 Gbps NL SATA
00NA597 ASLC 500GB 7.2K 6Gbps NL SATA 2.5" G3SS HDD 8
00NA622 ASLD 1TB 7.2K 6Gbps NL SATA 2.5" G3SS HDD 8
00NA536 AT82 2TB 7.2K 6Gbps NL SATA 2.5'' G3SS 512e HDD 8
Table 12. Internal drive options (Part 3: 3.5-inch hot-swap drives)
Part
number
Feature
code
Description Maximum
supported
3.5-inch hot-swap HDDs - 12Gbps SAS
00WG675 AT87 300GB 15K 12Gbps SAS 3.5" G2HS HDD 4
00WG680 AT88 600GB 15K 12Gbps SAS 3.5" G2HS HDD 4
3.5-inch hot-swap HDDs - 12 Gbps NL SAS
00FN188 A5VP 2TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 4
00FN208 A5VQ 4TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 4
00FN228 A5VR 6TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 4
3.5-inch hot-swap HDDs - 6 Gbps NL SAS
90Y8567 A26M 1TB 7.2K 6Gbps NL SAS 3.5" G2HS HDD 4
Lenovo System x3550 M5 20
