00NA105 6173 LTO Ultrium 4 Half High SAS DriveV2 Sled
00NA109 6173 LTO Ultrium 5 SAS Drive Sled
00NA111 6173 LTO Ultrium 5 Half High SAS Drive Sled
00NA117 6173 LTO Ultrium 6 Half High SAS Drive Sled
00WF767 6173 LTO Ultrium 7 Half High SAS Drive Sled
For more information, see the list of Product Guides in the Backup units category:
https://lenovopress.com/servers/options/backup
Top-of-rack Ethernet switches
The following table lists the top-of-rack Ethernet switches that are offered by Lenovo that can be used in
x3550 M5 solutions.
Table 35. Top-of-rack switches
Part number Description
1 Gb Ethernet top-of-rack switches
7159BAX Lenovo RackSwitch G7028 (Rear to Front)
7159CAX Lenovo RackSwitch G7052 (Rear to Front)
7159G52 Lenovo RackSwitch G8052 (Rear to Front)
10 Gb Ethernet top-of-rack switches
7159BR6 Lenovo RackSwitch G8124E (Rear to Front)
7159G64 Lenovo RackSwitch G8264 (Rear to Front)
7159DRX Lenovo RackSwitch G8264CS (Rear to Front)
7159CRW Lenovo RackSwitch G8272 (Rear to Front)
7159GR6 Lenovo RackSwitch G8296 (Rear to Front)
40 Gb Ethernet top-of-rack switches
7159BRX Lenovo RackSwitch G8332 (Rear to Front)
For more information, see the list of Product Guides in the Top-of-rack switches category:
http://lenovopress.com/servers/options/switches
Lenovo System x3550 M5 40
