00AG520 A56M Intel I350-T4 4xGbE BaseT Adapter 3
Part
number
Feature
code
Description Maximum
supported
* SFP+ and QSFP+ based adapters require supported transceivers or DAC cables that must be purchased
separately.
For more information, see the list of Product Guides in the Ethernet adapters category:
https://lenovopress.com/servers/options/ethernet
Storage host bus adapters
The following table lists storage HBAs supported by the x3550 M5 server.
Table 17. Storage adapters
Part
number
Feature
code
Description Maximum
supported
Fibre Channel - 16 Gb
81Y1662 A2W6 Emulex 16Gb FC Dual-port HBA 2
81Y1655 A2W5 Emulex 16Gb FC Single-port HBA 2
00Y3337 A3KW QLogic 16Gb FC Single-port HBA 2
00Y3341 A3KX QLogic 16Gb FC Dual-port HBA 2
Fibre Channel - 8 Gb
42D0494 3581 Emulex 8Gb FC Dual-port HBA 3
42D0485 3580 Emulex 8Gb FC Single-port HBA 3
42D0510 3579 QLogic 8Gb FC Dual-port HBA 3
42D0501 3578 QLogic 8Gb FC Single-port HBA 3
SAS
00AE912 A5M0 N2225 SAS/SATA HBA 3
00AE916 A5M1 N2226 SAS/SATA HBA 1
For more information, see the list of Product Guides in the Host bus adapters category:
https://lenovopress.com/servers/options/hba
PCIe SSD adapters
Lenovo System x3550 M5 26
