39Y8953 DPI Universal Rack PDU with Denmark line cord
39Y8954 DPI Universal Rack PDU with Israel line cord
39Y8955 DPI Universal Rack PDU with Italy line cord
39Y8956 DPI Universal Rack PDU with South Africa line cord
39Y8957 DPI Universal Rack PDU with UK line cord
39Y8958 DPI Universal Rack PDU with AS/NZ line cord
39Y8959 DPI Universal Rack PDU with China line cord
39Y8962 DPI Universal Rack PDU (Argentina)
39Y8960 DPI Universal Rack PDU (Brazil)
39Y8961 DPI Universal Rack PDU (India)
NEMA PDUs (6x NEMA 5-15R outlets)
39Y8905 DPI 100-127V PDU with Fixed NEMA L5-15P line cord
Line cords for PDUs that ship without a line cord
40K9611 DPI 32a Line Cord (IEC 309 3P+N+G)
40K9612 DPI 32a Line Cord (IEC 309 P+N+G)
40K9613 DPI 63a Cord (IEC 309 P+N+G)
40K9614 DPI 30a Line Cord (NEMA L6-30P)
40K9615 DPI 60a Cord (IEC 309 2P+G)
40K9617 DPI Australian/NZ 3112 Line Cord
40K9618 DPI Korean 8305 Line Cord
Part number Description
For more information, see the list of Product Guides in the Power infrastructure category:
https://lenovopress.com/servers/options/pdu
Rack cabinets
The following table lists the rack cabinets that are offered by Lenovo that can be used in x3550 M5
solutions.
Table 39. Rack cabinets
Part number Description
201886X 11U Rack Office Enablement Kit
93072RX 25U S2 Standard Rack
93072PX 25U Static S2 Standard Rack
93074RX 42U S2 Standard Rack
93634PX 42U 1100mm Enterprise V2 Dynamic Rack
93634EX 42U 1100mm Enterprise V2 Dynamic Expansion Rack
93604PX 42U 1200mm Deep Dynamic Rack
93614PX 42U 1200mm Deep Static Rack
93084PX 42U Enterprise Rack
93084EX 42U Enterprise Expansion Rack
For more information, see the list of Product Guides in the Rack cabinets category:
https://lenovopress.com/servers/options/racks
Lenovo System x3550 M5 43
