Optical drives
The x3550 M5 server supports the optical drive options listed in the following table. Server models with ten
2.5-inch drive bays on the front do not support an internal optical drive; a supported external optical drive
can be used instead.
Table 13. Optical drives
Part
number
Feature
code
Description Maximum
supported
Standard models
where used
00AM066 A5KG Ultraslim 9.5mm SATA DVD-ROM 1 -
00AM067 A5KH Ultraslim 9.5mm SATA Multi Burner 1 -
Ultraslim 9.5mm SATA DVD-ROM (part number 00AM066) supports the following media and speeds for
reading:
CD-ROM 24X
CD-DA (DAE) 24X
CD-R 24X
CD-RW 24X
DVD-ROM 8X
DVD-R 8X
DVD+R 8X
DVD-R DL 6X
DVD+R DL 8X
DVD-RW 8X
DVD+RW 8X
DVD-RAM (4.7 GB) 5X
Ultraslim 9.5mm SATA Multi Burner (part number 00AM067) supports the same media and speeds for
reading as DVD-ROM (part number 00AM066). This drive also supports the following media and speeds for
writing:
CD-R 24X
CD-RW 4X
High-Speed CD-RW 10X
Ultra Speed CD-RW 24X
DVD-R 8X
DVD+R 8X
DVD-R DL 6X
DVD+R DL 6X
DVD-RW 6X
DVD+RW 8X
DVD-RAM 5X
I/O expansion
The x3550 M5 server supports up to four PCIe slots: one on the system planar that is dedicated for an
internal RAID controller and up to three with different riser cards installed into two riser sockets on the
system planar (one riser socket supports the installation of one riser card). The slot form factors are listed:
Slot 1: PCIe 3.0 x16 or ML2; low profile, half-length (not present if the HDD Rear Kit is installed)
Slot 2: PCIe 3.0 x16 or PCIe 3.0 x8; low profile or full-height, half-length (PCIe 3.0 x16 slot requires
the second processor to be installed) (not present if the HDD Rear Kit is installed)
Slot 3: PCIe 3.0 x16 or PCIe 3.0 x8; low profile, half-length
Slot 4: PCIe 3.0 x8 (dedicated for an internal RAID controller)
Lenovo System x3550 M5 22
