Chapter 3
3-26BIOS Setup
OC PROFILE
Overclocking Prole 1/ 2/ 3/ 4/ 5/ 6
Overclocking Prole 1/ 2/ 3/ 4/ 5/ 6 management. Press <Enter> to enter the sub-
menu.
Set Name for Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Names the current overclocking prole.
Save Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Saves the current overclocking prole.
Load Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Loads the current overclocking prole.
Clear Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Clears the current overclocking prole.
OC Prole Save to USB
Saves OC prole to the USB ash disk drive. The USB ash disk should be FAT32
format only.
OC Prole Load from USB
Loads OC prole from the USB ash disk drive. The USB ash disk should be FAT32
format only.
▶
▶
▶
▶
▶
▶
▶
